What your Package Contains
Things you will Need
Camera Variants
The SATATYA Dome Cameras are available in two variants; Standard
and Premium. Both the variants are available in 5MP with 2.8mm,
4.0mm and 6.0mm fixed focal length.
5
• Bullet IP Camera Unit
• Wall Mounting Template
• Wall Mounting Screws with Screw Grip (3 nos.)
• Allen Key
• Cable Accessories
• A Power Drill, Screwdriver Set, Pliers, Wire-cutter, Ladder.
• Necessary Cabling
• A Power Supply with the recommended output voltage of 12V DC.
Use an Adapter to connect the camera to the power outlet.
You can capture near and broader view with lens of 2.8mm
and 4.0 mm focal length. For example it can be used in ATM
and Elevators.
With lens of 6 mm focal length, far and narrow view can be
captured. For example it can be used in corridors or long
passage to capture long view.
Type of
Lens
Focal
Length
Fixed
4.0mm
6.0mm
MIDR50FL40CWS
Premium
Standard
MIDR50FL60CWS
2.8mm
MIDR50FL28CWS
MIDR50FL28CWP
MIDR50FL40CWP
MIDR50FL60CWP
Fixed
Fixed
6
The 5MP Camera variants are listed in below table,
1. This product is intended to be supplied by a UL listed power
supply unit marked “Class 2” or “LPS” or “PS2” and rated 12VDC,
2A min.
2. The wired LAN hub providing Power over the Ethernet (PoE) in
accordance with IEEE 802-3af shall be a UL listed device with the
output evaluated as a limited power source as defined in UL60950-1
or Ps2 as defined in UL62368-1.
Installation Instruction
