Matrix SATATYA Professional Series User Manual

Step 6: Adjusting Camera Angle
Loosen the screws on both sides of lens to adjust the camera angle,
see Figure 6.
A. PAN Movement
For PAN movement you can move the camera to 45 degrees each
side. see Figure 7. To capture other side view, turn the body and
mount to other side.
Screws
Figure 6
Mounting
Template
Wall/Ceiling
Figure 5
11
12
45.0°
45.0°
Figure 7

Matrix SATATYA Professional Series Specifications

General

Brand	Matrix
Model	SATATYA Professional Series
Category	Security Camera
Language	English
