• To mount the camera, you need to detach the Top Enclosure.
• Use the Allen Key to loosen the Retainer screws on three sides of
the camera body, as shown in Figure 4a.
• The Retainer screws will still remain loosely connected.
• Now, pull the Top Enclosure downwards. The Top and Bottom
Enclosures are detached.
Step 5: Mounting the Bottom Enclosure
Figure 4a
Botttom
Enclosure
Top
Enclosure
Allen
Key
