2 Matrix SETU VFXTH Quick Start
SETU VFXTH0032
Ports and Connectors
System Status Color STS
Reset Button --- To restart the system or to restore the default IP Address.
Ethernet RJ45 To connect to the IP network over a DSL Modem or Router or a LAN Swtich.
P01 to P32
a
(FXS Ports)
a. If your SETU VFXTH supports only FXO Ports (SETU VFXTH3200), P01 to P32 will be used to connect
PSTN lines or a PBX. However, if you system supports both FXO and FXS Ports (SETU VFXTH0808) then
P01 to P08 (FXO Ports) will be used to connect PSTN lines or a PBX and P09 to P16 (FXS Ports) will be
used to connect telephone instruments or a Fax Machine or a PBX.
RJ11 To connect standard telephone instruments, or a Fax Machine or a PBX.
24VDC-
2.5A(Max)
DC Jack To connect 24VDC, 2.5A power adapter.
Ethernet
Port
Reset
Button
P01 to P32
FXS Ports
Power
Adapter
FAN
