Matrix SETU VFXTH User Manual

Matrix SETU VFXTH Quick Start 7
Powering ON SETU VFXTH
•Connect the power adapter to SETU VFXTH.
• Plug in the power adapter of SETU VFXTH into the power outlet.
• Switch on power supply and wait for the Reset Cycle to complete.
Reset Cycle
The Reset Cycle (Power-ON Self Test) takes about 2 minutes to finish.
LED Indication - Reset Sequence
At Power ON, Power LED will turn ON (Continuous Green). Initialization process will start within
15 to 20 seconds and LED sequence of all other LEDs during initialization process is shown in the
table given below:
• During Off-hook state, FXS Port LED glows Red continuously.
• If the system is in programming mode, the LED of the port used to enter the programming
mode glows Green continuously. After exiting programming mode, the LED for that port glows
Red (to indicate Off-hook state).
You may now access the web-based programming tool, Jeeves, and configure SETU VFXTH.
System
Status
Color STS P01 P02 P03 P04 P05 P06 …. P32
Time
(ms)
Application
Load
Red OFF ON ON ON OFF OFF OFF OFF OFF
All Init
Done,
System
goes Live
Red ON ON ON ON ON ON ON ON ON
1000
ms
OFF OFF OFF OFF OFF OFF OFF OFF OFF
1000
ms

Matrix SETU VFXTH Specifications

General

Brand	Matrix
Model	SETU VFXTH
Category	Gateway
Language	English
