Matrix SETU VFXTH User Manual

Matrix SETU VFXTH Quick Start 4
Installing SETU VFXTH
Before You Start
• Select a suitable location to mount SETU VFXTH.
• Keep the following ready:
• Necessary telecom wiring as well as cable.
• A standalone PC to access the web based configuration tool, Jeeves.
• A SIP Account information to test VoIP connectivity.
• An active trunk line from the PSTN, if required.
•Any standard telephone instrument, if required.
• Do not install this product near any area where,
• it is exposed to direct sunlight, heat, excessive cold or humidity, dust, oil, corrosive fumes.
• there is a water source (wash basin, tub, shower, pool, sprinkler, etc.)
• there is source of electromagnetic noise such as radio equipment, heavy transformers,
faulty electric chokes of tube-lights, device having a faulty coil.
• Ensure proper electrical earth and telecom earth for the safety of the product and persons
handling it.
• Always wear an electro static discharge preventive wrist wrap or belt and use a grounding mat
when handling the product and its parts.
• Battery: SETU VFXTH contains 3.3V DC Manganese Lithium Battery (ML 2032- Rechargable) of
diameter 20 (-0.2)mm and height 3.2 (-0.3)mm. Battery should be replaced only by authorized
dealers of Matrix. There is a risk of explosion if the Battery is replaced in an incorrect manner.
Please dispose-off used Batteries.
Getting Started
Package Contents
• Unpack the SETU VFXTH package and check the package contents:
•SETU VFXTH Unit
• Power Adapter - 24VDC, 2.5A (Country Specific)
• Ethernet Cable (RJ45)
• Two Screws M7/30 with grips
• Two 19 inch Rack Mounting Clamps
• Mounting Template
• Warranty Card Set

Matrix SETU VFXTH Specifications

General

Brand	Matrix
Model	SETU VFXTH
Category	Gateway
Language	English
