Matrix Versa Single-Station Strength - Installation & Assembly: Value Line Part 1 Weight Stack to User Frame Assembly

10
PART 1: USER FRAME ASSEMBLY
STEP 1 | USER FRAME INSTRUCTIONS & NOTES
1
2
4
3
5
7
8
6
ID DESCRIPTION QUANTITY
1 Weight Stack 1
2 M10 Flat Washer 6
3 M10 X 20L SHC 2
4 Lower Connecting Tube 1
5 M10 Nylock Nut 2
6 User Frame 1
7 Wide Cupped Flange 1
8 M10 X 125L SHC 2
Install the user frame hardware as shown, but DO NOT FULLY TIGHTEN .
ASSEMBLY
