31
ASSEMBLY
PART 7: SHORT USER KIT ASSEMBLY
SHORT USER KIT ASSEMBLY INSTRUCTIONS & NOTES
4SK
2SK
3SK
1SK
5SK
ID DESCRIPTION QUANTITY
1SK M10 X 18L SHC 1
2SK M10 Flat Washer 4
3SK Coupler Plate 2
4SK M10 X 18L Hex Bolt 2
5SK Foot Rest 1
