Matrix Versa Single-Station Strength - Part 4 Seat Pad Assembly

18
STEP 1 | BACK PAD AND HEAD PAD ASSEMBLY INSTRUCTIONS & NOTES
2
31
30
29
ID DESCRIPTION QUANTITY
2 M10 Flat Washer 4
29 Head Pad 1
30 Back Pad 1
31 M10 X 75L SHC 4
Install the head & back pads as shown.
Tighten to 57 N-m/41 ft-lbs.
ASSEMBLY
PART 4: SEAT PAD ASSEMBLY
