Matrix Versa Single-Station Strength User Manual

8
ID
DESCRIPTION
QTY
1 Weight Stack 1
2 M10 Flat Washer 18
3 M10 X 20L Socket Head Cap Screw 6
4 Lower Connecting Tube 1
5 M10 Nylock Nut 4
6 User Frame 1
7 Wide Cupped Flange 2
8 M10 X 125L Socket Head Cap Screw 4
9 Upper Connecting Tube 1
10 Right Arm Assembly 1
11 Left Arm Assembly 1
12 M12 Large Flat Washer (Ø40 mm) 4
13 Belleville Washer 2
14 M10 X 30L Socket Head Cap Screw 2
15 Ø20 mm Shaft 2
16 Counter Weight 2
17 M8 Flat Washer 4
18 M8 X 20L Socket Head Cap Screw 4
19 M12 Flat Washer 2
20 M12 X 25L Socket Head Cap Screw 2
21 Pulley (Ø3.5”) 10
22 M10 X 50L Socket Head Cap Screw 3
23 Floating Pulley Plate 2
24 M8 X 45L Socket Head Cap Screw 1
25 M8 Nylock Nut 3
26 Cable Tie Rod End 3
27 User Frame Cable 1
28 M8 X 50L Socket Head Cap Screw 2
29 Head Pad 1
Parts List
