24
ASSEMBLY
STEP 4 | PREMIUM KIT ASSEMBLY INSTRUCTIONS & NOTES
PART 8: PREMIUM KIT ASSEMBLY
Wing
Assemble the wing (1P) as shown using the
M8 hardware provided with the kit. Tighten
to 39N-m (29 ft-lbs.).
