28
Appendix B, Matrox Multi Specifications
General
• Video formats NTSC, PAL, 1080p/i/PsF, 720p, 576PsF, 486PsF
• Regulatory compliance
$ FCC Class B, CE Mark Class B, ACMA C-Tick Mark, VCCI
$ RoHS Directive 2002/95/EC
• Matrox Multi card
$ Standard three-quarter-length PCIe (x8) card
$ PCB dimensions: 231.8 mm × 106.7 mm (9.125" × 4.2")
• Typical operating voltages and current consumption
Connections
• Genlock reference input (REF IN)
$ HD analog tri-level sync or SD analog bi-level black burst
$ BNC connector (75 Ω)
$ User-configurable termination
• Genlock reference output (REF OUT)
$ HD analog tri-level sync or SD analog bi-level black burst
$ Loop through
$ BNC connector (75 Ω)
• Longitudinal time code (LTC) input
$ Compliant with SMPTE 12M
$ BNC connector (75 Ω)
• RS-422 D-sub connector (9 pins)
Video
• SDI input (Multi-Ingest/Multi-I/O)
$ 16 channels of embedded SDI audio (SMPTE 272M, 299M)
$ 24-bit, 48 kHz
$ SD/HD: Compliant with SMPTE 259M, 292M, and 424M
$ BNC connector (75 Ω), terminated
$ Equalized input for maximum cable length support
Voltage +3.3 V +12 V
Current 3.0 A 1.1 A
Total power consumption: 23.1 watts
