2 How to remove the Tie-Wire
● Be sure to turn the Main switch OFF, lock the Trigger, and remove the Battery
pack.
① Press the release lever, and confirm that the release lever is caught in the release
stopper.
Release Stopper
Release Lever
Wire guide
Tie-Wire
Tie-Wire
Reel stopper
② Remove the Tie-Wire.
③ Push the reel stopper to release the holder and remove the Tie-Wire.
④ Mount the new Tie-Wire. (Refer to the Tie-Wire mounting method explanation.)
When the Tie-Wire runs out of binding wire
There should be around 30 mm (1-1/8”) of the Tie-Wire left at end of the spool. This should be discharged with
the old spool and be replaced with a new one.
