RB215
3 Wire length adjustment
Battery pack
Edge part
Edge part
Feed dial
Main switch
Battery pack
HIGHLOW
① Be sure to turn the main switch OFF, to lock the trigger and detach the battery
pack.
② The feed dial is a mechanism to adjust feed rate of the Tie-Wire. When the edge
part length is not appropriate after binding, use this dial to adjust it.
③ Mount the battery pack on the tool’s main body insert the charged battery pack on
to the main unit until a click is heard.
● When setting the main switch to ON, absolutely do not bring your hand
close to the binding part or rotating part of the tip.
④ Set the Trigger Lock to UNLOCK and turn on the main switch.
The Tie-Wire is fed automatically to the arm unit and set in the required position.
⑤ Test the tool again to check the tie strength.
18
