Max Re-Bar-Tier Twintier RB441T User Manual

11
5. TOOL SPECIFICATIONS AND TECHNICAL DATA
<BATTERY CHARGER>
<BATTERY PACK>
PRODUCT DESCRIPTION MAX Rebar Tying tool “TWINTIER”
PRODUCT NO. RB441T(CE)
DIMENSIONS (Battery pack included) (H)295mm x (W)120mm x (L)330mm
WEIGHT (Battery pack included) 2.5kg / 5.6lbs
BATTERY Lithium ion Battery pack / JPL91440A
OPERATING TEMPERATURE -10°C to 40°C / 14°F to 104°F
HUMIDITY 80% RH or less
PRODUCT DESCRIPTION Lithium ion Battery charger
PRODUCT NO. JC925(CE)
INPUT AC220-240V 50/60Hz 1.4A 160W
OUTPUT DC14.4V 7.5A, DC18V 5.4A, DC25.2V 4.5A
WEIGHT 1.5kg / 3.3lbs
OPERATING TEMPERATURE RANGE 5°C to 40°C / 41°F to 104°F
OPERATING HUMIDITY RANGE 80% RH or less
PRODUCT DESCRIPTION Lithium ion Battery pack
PRODUCT NO. JPL91440A
NOMINAL VOLTAGE DC14.4V(3.6V x 4cells)
NOMINAL CAPACITY 3.9Ah (3,900mAh)
CHARGING TIME Quick charging – Approx. 33min.(Approx. 90% of capacity)
Full charging – Approx. 45min.(100% of capacity)
ACCESSORIES Pack cap
WEIGHT 0.5kg / 1.1lbs
CHARGING TEMPERATURE 5°C to 40°C / 41°F to 104°F
OPERATINGTEMPERATURE RANGE 0°C to 40°C / 32°F to 104°F
OPERATING HUMIDITY RANGE 80% RH or less
TIES PER CHARGE Approx. 4,000 ties (*under the following conditions: normal temperature,
unused, full-charged battery and 13mm x 13mm / #4 x #4 rebars)

Max Re-Bar-Tier Twintier RB441T Specifications

General

Tool Type	Rebar Tying Tool
Model	RB441T
Battery Type	Lithium-Ion
Battery Capacity	4.0Ah
Applicable Rebar Size	#3 x #3 to #7 x #7
Brand	Max
Weight	2.6 kg (including battery)
Ties per Charge	Approximately 4000 ties
Wire Diameter	0.8 mm
