12.OPERATING INSTRUCTIONS
1. How to set the Tiewire
(Fig.6) Set the Main switch (e) at "OFF", the
Trigger lock (2) at "LOCK" and remove the
Battery pack (5).
• Be careful not to drop or give a strong
impact to the Tiewire. It may cause the
damage and the malfunction of the tool.
• Beware of the tip of the wire when you pick
up the Tiewire. It might cause an injury.
1-1 (Fig.9) Press the Release button (8) of this
tool, and confirm that the Release button is
caught in the Release stopper (9).
1-2 (Fig.10) Stretch out the tip of the wound
Tiewire.
BE SURE TO USE ONLY THE SPECIFIED
TIEWIRE (MAX TW1061T Series).
The use of binding wire that has not been
specified may cause breakdown of this tool.
Therefore, be sure only to use the specified MAX
TW1061T series.
RB441T is not compatible with TW898 series or
TW1525 series.
DO NOT USE RUSTY WIRE.
The use of the rusty wire may cause functional
trouble of the tool.
1-3 (Fig.11) Rotate the Magazine stopper (6)
45° counterclockwise.
1-4 (Fig.12,13) Open the Magazine cover (n)
and set the Tiewire in the Magazine (7) with
the Holding slot (o) side of the reel facing
up.
1-5 (Fig.14) Grasp the tool with the left hand,
hold the tip of the wire with the right hand,
and remove the wire from the Holding slot.
The 2 wire tips of new Tiewire are twisted.
1-6 (Fig.15) Straighten out the tip of the wire,
and insert the twisted wire into the Wire
guide (i) parallel.
1-7 (Fig.16) Confirm through the Window that
the twisted part of wire has reached past two
Feeding gears (h).
1-8 (Fig.17) Press the Release stopper (9) up,
and confirm that the Release button has
been raised up.
1-9 (Fig.18) Close the Magazine cover and
rotate the Magazine stopper 45° clockwise.
If the Window is dirty
Open the Window (Fig.1.g) and wipe off the dirt
on the inside of the Window with a cloth. Close
the Window again after cleaning to ensure that
foreign objects will not be able to enter the tool.
2. How to operate RB441T
(Fig.6) Set the Main switch (e) at "OFF", the
Trigger lock (2) at "LOCK" and remove the
Battery pack (5).
2-1 (Fig.19) Mount the Battery pack on the tool's
main body until a click is heard.
2-2 (Fig.20) When Main switch (e) is turned
"ON", the Hook (Fig.1.f) of the tip rotates
automatically for initializing, absolutely do
not bring your fingers close to any rotating
and moving part. Set the Main switch at "ON"
and the trigger lock (2) at "UNLOCK".
2-3 (Fig.21) Tilt the tool 45° angle to the crossed
rebars.
2-4 (Fig.22) Align the Center mark (a) to the
center of the crossed rebars.
2-5 Once pull the Trigger, the tool automatically
completes a series of tying actions (feeding,
cutting, gripping and tying).
• (Fig.23) When the Main switch (Fig.1.e) is
turned "ON", the Hook (Fig.1.f) of the tip
rotates automatically for initializing,
absolutely do not bring your fingers close
to any rotating and moving part.
• Do not touch any rotating and moving part
such as hook of the tip or the Tiewire
during the tying work (while the machine is
operating).
3. How to remove the Tiewire
(Fig.6) Set the Main switch (e) at "OFF", the
Trigger lock (2) at "LOCK" and remove the
Battery pack (5).
3-1 (Fig.9) Press the Release button (8) of the
tool and confirm that the Release button is
caught in the Release stopper (9).
CAUTION
NOTICE
WARNING
