16
3-2 (Fig.11) Rotate the Magazine stopper (6) to
open the Magazine cover.
3-3 (Fig.24) Remove the Tiewire from the
Magazine.
3-4 (Fig.25) Remove the wire with the plastic
piece from the Wire guide.
4. When the Tiewire runs out
(Fig.26) The plastic piece comes off when it is
used up normally, and can be discarded
separately as plastic and metal wire. (About 20
cm remains after normal use)
(Fig.6) Set the Main switch (e) at "OFF", the
Trigger lock (2) at "LOCK" and remove the
Battery pack (5).
5. Tension adjustment
(Fig.27.c) This dial allows you to adjust wire
tension torque slightly. To increase the tension,
turn it in the counterclockwise. To decrease the
tension, turn it in the clockwise.
6. Auto Power-off feature
This tool has "Auto Power-off" feature, which
saves the power consumption of the Battery
when the tool is not operated.
If the tool is not operated for 30 minutes, the tool
is automatically turned off. When the power is
turned off automatically, turn the Main switch
OFF and ON again to operate the tool.
7. For proper tightness
7-1 (Fig. 21) Tilt the tool 45° angle to the crossed
rebars.
7-2 (Fig.22) Align the Center mark (a) to the
center of the crossed rebars.
7-3 (Fig.28) Apply the tool perpendicularly to the
surface of the crossed rebars.
During tool operation
Do not move the tool during tying operation until
the tool stops tying automatically.
7-4 (Fig.29) Tie in alternate direction.
7-5 (Fig.30) Cross tying.
Bent the knot of the first tie before making
the second tying.
8. How to reload previously used
Tiewire
(Fig.31) Without twisting the 2 wires, insert them
into the Wire guide (i).
13.STORAGE
Do not store the tool in a cold weather
environment. Keep the tool in a warm area.
When not in use, the tool should be stored in a
warm and dry place. Keep out of reach of
children.
REMOVE REEL OF TIEWIRE
When you have finished the Tiewire, remove the
reel from the tool.
STORE THE TOOL
When you have finished tying work or when the
tool will not be used for a while, set the Main
switch (Fig.1.
e
) at "OFF", the Trigger lock
(Fig.1.
2
) at "LOCK" and remove the Battery pack
(Fig.1.
5
). The tool and accessories should be
stored in a well-ventilated dry place where the
temperature will not exceed 40°C (104°F).
The Battery pack with the Pack cap (Fig.2.
k
) to
prevent short circuits should be stored in a well-
ventilated dry place where the temperature will
not exceed 30°C (86°F).
