Maxcess CL Series - Specifications

6–1
SPECIFICATIONS
www.maxcessintl.com MAGPOWR CL Load Cells MI 850A192 J 1
Specifications
WARNING – Do not use the devices outside of their rated specifications.
Gage Resistance
350 ohm
Gage Type
Metal foil, full bridge
Excitation Voltage
10 VDC maximum
Output Signal
21 mVDC maximum at full load rating
Operating Temperature
-30ºC to 80ºC
Temperature effect on zero
0.02% of rating per ºC
Combined non-linearity and
hysteresis
0.5% of full scale maximum
1.5% of full scale maximum for CL2-500
Repeatability
0.2% of full scale maximum
Overload stops
105% to 150% of full load rating
Deflection at full load
0.279 mm [0.011 inch]
Weight
CL1-x = 0.45 kg [1.0 lb]
CL2-x = 0.82 kg [1.8 lb]
Cable Connector
M12 (standard) page 3-2
Climate Class
3K4 (EN60721)
IP Protection Classification
IP67 (EN60529)
