10 TECHNICAL DATA - WINCH SPECIFICATIONS
SERIES 3300W STANDARD EQUIPMENT
Electric winch Remote control with connection and 8 m. - 26’ ft. of cable
Negativ brake for winch
Load limiting device Solenoid valve with manual functions (only for emergency)
Rotation with worm-gear Stop-end system for winch (up and down)
TECHNICAL DATA 3300W
Crane rating KNm 16
Standard outreach m 4,5
Slewing angle 400°
Boom elevation (-5° +80°)
Lifting height from base of crane m 4.5
Remote control ON/OFF
Pump for electrical “E” 12V l/min 1.5 - 3.5
Working pressure bar 160
Crane weight Kg 240
WINCH SPECIFICATION 3303W
Winch pull line daN 730
Pull line speed without load E 12V m/min 6
Rope diameter mm6
Wire rope length m 25
Cable breaking strength Kg minimum 3650
Technical data not binding
Pict. 17
LOAD CAPACITIES COBRA 3300W
