Maxim Integrated Page 20 of 52
HOST COMMAND
MAX32664
FAMILY NAME
DESCRIPTION
FAMILY
BYTE
INDEX
BYTE
WRITE BYTES
RESPONSE BYTES
Set Output
Mode
Set the output format
of the sensor hub.
(MAX32664GWEA,
MAX32664GWEB,
MAX32664GWEC,
MAX32664GWED)
0x10
0x00
0x00: Pause (no data)
0x01: Sensor Data
0x02: Algorithm Data
0x03: Sensor Data and
Algorithm Data
0x04: Pause (no data)
0x05: Sample Counter byte,
Sensor Data
0x06: Sample Counter byte,
Algorithm Data
0x07: Sample Counter byte,
Sensor Data and Algorithm
Data
-
Set Output
Mode
Set the threshold for
the FIFO interrupt
bit/pin.
The MFIO pin is used
as the interrupt and
the host should
configure this pin as
an input interrupt
pin. The status bit
DataRdyInt is set
when this threshold
is reached.
(MAX32664GWEA,
MAX32664GWEB,
MAX32664GWEC,
MAX32664GWED)
0x10
0x01
0x01 to 0xFF: Sensor Hub
Interrupt Threshold for FIFO
almost full.
-
Read Output
Mode
READ the output
format of the sensor
hub.
(MAX32664GWEA,
MAX32664GWEB,
MAX32664GWEC,
MAX32664GWED)
0x11
0x00
0x00: Pause (no data)
0x01: Sensor Data
0x02: Algorithm Data
0x03: Sensor Data and Algorithm Data
0x04: Pause (no data)
0x05: Sample Counter byte, Sensor
Data
0x06: Sample Counter byte, Algorithm
Data
0x07: Sample Counter byte, Sensor
Data and Algorithm Data
