HOST COMMAND
MAX32664
FAMILY NAME
DESCRIPTION
FAMILY
BYTE
INDEX
BYTE
WRITE BYTES
RESPONSE BYTES
Algorithm
Configuration
BPT algorithm: Write
the three samples of
the diastolic BP byte
values needed by the
calibration
procedure.
(MAX32664GWED)
0x50
0x04
0x01, diastolic value 1,
diastolic value 2, diastolic
value 3
-
Algorithm
Configuration
BPT algorithm: Write
the three samples of
the systolic BP byte
values needed by the
calibration
procedure.
(MAX32664GWED)
0x50
0x04
0x02, systolic value 1, systolic
value 2, systolic value 3
-
Algorithm
Configuration
BPT algorithm: Write
the calibration data
for this user.Calibrate
the BPT algorithm
using the result of the
calibration
procedure. (Use the
data from the 0x51
0x04 0x03
command).
(MAX32664GWED)
0x50
0x04
0x03, 824608 bytes of
calibration data
-
Algorithm
Configuration
BPT algorithm: Set
the estimation date,
using the current
date. The year is sent
as a 16-bit unsigned
integer, and the
month and day are
bytes.
0x50
0x04
0x04, year MSB, year LSB,
month, day
-
Algorithm
Configuration
BPT algorithm:
Configure whether
the user is not resting
or resting.
(MAX32664GWED)
0x50
0x04
0x05, 0x00: Resting
0x05, 0x01: Not resting
-
Algorithm
Configuration
BPT algorithm: Set
the SpO
2
coefficients
A, B, C.
Defaults:
C = 0x42E16137
B = 0xC20AA37F
A =
3FCC448F(MAX3266
4GWED)
0x50
0x04
0x0B, four bytes signed
integer A, four bytes signed
integer B, four bytes signed
integer C (32-bit integers
which are the coefficients
times 100,000)
The MAXREFDES220#
without the cover glass uses
the following coefficients as
the default values:
A = 159584
B = -3465966
C = 112689870x06, four bytes
float C, four bytes float B, four
bytes float A
-
