HOST COMMAND
MAX32664
FAMILY NAME
DESCRIPTION
FAMILY
BYTE
INDEX
BYTE
WRITE BYTES
RESPONSE BYTES
Algorithm
Configuration
Read
WSpO
2
algorithm:
Read the PD
configuration (source
of PPG signal).
(MAX32664GWEC)
0x51
0x05
0x09
0x01: PD1
0x02: PD2
0x03: PD1, PD2
Algorithm Mode
Enable
AGC: Enable the AGC
algorithm.
(MAX32664GWEA)
0x52
0x00
0x00: Disablee
0x01: Enable
-
Algorithm Mode
Enable
AEC: Enable the AEC
algorithm.
0x52
0x01
0x00: Disable
0x01: Enable
-
Algorithm Mode
Enable
WHRM, MaximFast:
Enable the WHRM,
MaximFast
algorithm.
(MAX32664GWEA,
MAX32664GWEB)
0x52
0x02
0x00: Disable
0x01: Enable Mode 1
0x02: Enable Mode 2
(See Table 8 for Algorithm
Mode definitions)
-
Algorithm Mode
Enable
Electrocardiogram
(ECG): Enable the
ECG algorithm.
(MAX32664GWEB)
0x52
0x03
0x00: Disable
0x01: Enable
-
Algorithm Mode
Enable
Blood Pressure
Trending (BPT):
Enable the BPT
algorithm.
(MAX32664GWED)
0x52
0x04
0x00: Disable
0x01: Enable Calibration
Mode
0x02: Enable Estimation
Mode
-
Algorithm Mode
Enable
WSpO
2
: Enable the
algorithm.
(MAX32664GWEC)
0x52
0x05
0x00: Disable
0x01: Enable Mode 1
-
Bootloader
Flash
Set the initialization
vector (IV) bytes.
(MAX32664GWEA,
MAX32664GWEB,
MAX32664GWEC,
MAX32664GWED)Thi
s is not required for a
non-secure
bootloader.
0x80
0x00
Use bytes 0x28 to 0x32 from
the .msbl file as the IV bytes
-
Bootloader
Flash
Set the
authentication
bytes..
This is not required
for a non-secure
bootloader.(MAX326
64GWEA,
MAX32664GWEB,
MAX32664GWEC,
MAX32664GWED)
0x80
0x01
Use bytes 0x34 to 0x43 from
the .msbl file.
-
Bootloader
Flash
Set the number of
pages.
(MAX32664GWEA,
MAX32664GWEB,
MAX32664GWEC,
MAX32664GWED)
0x80
0x02
0x00, Number of pages
located at byte 0x44 from
the .msbl file.
-
