Maxima 2 - Noise

Chapter 2
Technical Specifications
17
TEST DOCUMENTS AND CERTIFICATES FOR THE INSTRUMENTS USED FOR THE MEASUREMENTS
ARE FILED AT MAXIMA AND ARE AVAILABLE FOR THE MONITORING AUTHORITIES.
Model
MAXIMA 2
MAXIMA 5
Dimensions
L (mm)
250
280
P (mm)
410
440
H (mm) 400
400
H2 (mm) 215 200
P2 (mm) 145 145
E (mm) 200 200
RATED POWER / RATED CURRENT
Power
supply voltage (Volts)
Frequency (Hz)
Phases
MAX 2
MAX 5
230
50
1
0.3 kW - 4 A
0.4 kW - 4 A
220
60
1
0.3 kW - 5 A
0.4 kW - 5 A
2.5 Noise
The machine is designed and built to conform to the requirements of the regulations in force.
The machine’s exposure limit and action limit values, relative to the level of daily exposure to the peak noise and acoustic
pressure, are respectively less than 80 dB(A) and 135 dB(C). Test documents and certificates for the instruments used for
the measurements are filed at MAXIMA and are available to monitoring authorities.
