No. Part No. Description No. Part No. Description
1 5610220000 Screw 32 3420356000 Housing
2 3320366000 Rear Cover 33 3550592000 Spindle Lock
3 5610017000 Screw 34 5660005000 “E’’ Ring
4 3121518000 Transparent
Cap
35 3660174000 Stop Spring
5 4900247000 PCB Plate 36 5630179000 Nut
6 3122851000 Seal Ring 37 5630187000 Collet Nut
7 4870073000 Switch 38 3550721000 Collet
8 5610059000 Screw 41 5620024000 Screw
9 5610106000 Tapping Screw 42 3320363000 Right Handle
10 3122798000 Cord
Anchorage
43 3320368000 Left Handle
11 4540017000 Power Indicator
Light
44 3400189000 Lock Bolt
12 5620017000 Screw 45 3420471000 Mounting
13 4810002188 Power Cord 46 3121637000 Chip Shield
14 3121050000 Cord Guard 47 3122840000 Base Plate
15 3120537000 Brush Cap 48 5660003000 E Ring
16 4960019000 Carbon Brush 49 3660167000 Spring
17 2800005000 Brush Holder 50 3520147000 Lock Gear
18 3121494000 Middle Housing 51 3520141000 Gear
19 2740118000 Stator 52 3550579000 Gear Shaft
20 5610050000 Screw 53 3121648000 Button
21 3123926000 Bearing Holder 54 3550613000 Shaft
22 3121049000 Rubber Spring 55 3550615000 Worm
23 3700249000 Washer 56 5620033000 Screw
24 5700008000 Bearing 57 3121647000 Indicator Ring
25 3121495000 Fan Baffle 58 3121646000 Adjusting
Knob
26 2750184000 Rotor 59 5620041000 Screw
27 5620040000 Screw 60 5620332000 Screw
28 2820887000 LED 61 3550596000 Lock Pin
29 5700056000 Bearing 62 3420395000 Clamping
Lever
30 5620062000 Screw 63 3700848000 Plate
31 3520227000 Gear Rack 64 5630015000 Lock Nut
PART LIST
