No. Part No. Description No. Part No. Description
65 5620049000 Screw 92 3660166000 Spring
66 5650172000 Washer 93 3123581000 Bellows Seal
67 5670040000 Located Pin 94 5690120000 “O’’Ring
68 5620032000 Screw 95 3550576000 Long Plunge
Rod
69 3120200000 Depth
Adjusting Cap
96 3550575000 Plunge Rod
70 5690002000 “O’’ Ring 97 5620103000 Screw
71 3550791000 Depth Stop Bar 98 5650007000 Gasket
72 3550083000 Adjusting Pole 99 3420387000 Turn Table
73 3121634000 Depth Indicator 100 5700046000 Steel Ball
74 5610042000 Screw 101 3660030000 Spring
75 3320369000 Left Handle
Cover
102 3121583000 Chip Shield
76 5620023000 Screw 103 5670158000 Spring Pin
77 3320365000 Left Handle 104 3420370000 Mounting
78 3320364000 Right Handle 105 3122841000 Base Plate
79 3320367000 Right Handle
Cover
106 5620050000 Screw
80 3121639000 Cover 107 5650015000 Spring Washer
81 5660018000 Circlips of
Shaft
108 5650013000 Plain Washer
82 3700078000 Spring Washer 109 3703591000 Parallel Guide
83 3420398000 Plunge Lock
Lever
110 3550683000 Guiding Rod
84 3660254000 Torsion Spring 111 3122784000 Vacuum
Adapter
85 5640045000 Bolt 112 3550595000 Collet
86 5670039000 Pin 113 5620040000 Screw
87 3420390000 Clamping Lever 114 3121599000 Vacuum
Adapter
88 3550577000 Mitre Lock Bolt 115 3700807000 Wrench
89 3420470000 Plunge Frame 117 3700806000 Guide Bush
90 5700055000 Oil Impreging
Bearing
118 5630003000 Nut
91 3520138000 Bush 119 5630187000 Collet Nut
