1.1 HARDWARE SPECIFICATIONS
Interfaces
WAN
• RJ11 DSL line port
• GE uplink - ETH WAN Gigabit
• Full FX0
LAN
• 3-port autosensing 10/100Base-T auto-MDI/MDI-X Ethernet switch
• 1-port Gigabit Ethernet LAN
• 2 FXS POTS interfaces
• 2 USB 2.0 hosts/masters
• Wi-Fi IEEE 802.11b/g/n on board
Extras
Restore factory defaults button
WPS
Dimensions (h x d x w)
19.5 x 6 x 23cm (9 x 2.4 x 9.7 in.)
AC Voltage
100-240 VAC (switched mode power supply)
Temperature
0°- 40°C (32 - 104 F)
Humidity
20% to 80%
RESIDENTIAL GATEWAY MODEL TG799VN | 4
1. TECHNICAL SPECIFICATIONS
