10- FAULT EVENT MESSAGE FORMAT ON LCD SCREEN
On fault event, the panel displays a message in 6 lines as shown below; fault relays get
activated and buzzer rings.
Z o n e s I n A l a r m : 0 D i s . : 0 F a u l t : 1
* F A U L T - M G 9 4 0 0 M u l t i s e n s o r Z o n e : 1 *
P : 0 L : 1 A : 2 8 M L - 1 2 X X A u t o - l e a r n e d
M E E T I N G R O O M
D i s c o n n e c t e d D e v i c e
1. In the 1
st
row following information is displayed;
Zone In Alarm: Number of Alarm at the zones.
Disablements: Total number of disablements
Fault: Total number of faults
2. 2
nd
row is empty.
3. In the 3
rd
row; the device model and zone information is displayed.
4. In the 4
th
row; location information of the faulty device is displayed. (Panel No., the
faulty device (like SLCU, PCU, NCU), address information if the device is addressable,
panel name)
5. In the 5
th
row; zone location text of the faulty device is displayed.
6. In the 6
th
row; fault type is displayed.
11- PANEL MENU
There are 3 access levels in order to prevent unauthorized access.
a) Access level 1: ‘Button Control’ key is ‘Disabled’. In this case; ‘Silence Buzzer’, ‘Lamp
Test’, ‘More Fires’, ‘More Events’ buttons can be used. ‘Button Control’ key must be switched
ON in order to unlock other buttons.
b) Access level 2: Some menu functions are active in this access level. Press ‘Enter’ while
‘Button Control’ key is enabled to access panel menu.
The button number ‘1’ is used to move ‘up’, and the button number ‘3’ is used to move
downward. To confirm the selected option press ‘enter’ button or press the button number ‘2’.
In order to get back to previous menu, press ‘Exit’ or press the button number ‘4’.
ACCESS LEVEL 2 MENU
+DEVICES
+DISABLEMENTS
+SET SYSTEM TIME
+FIRE ALARM COUNTER
+DELAY CONFIGURATION
+TEST
+ACCESS LEVEL 3
ACCESS LEVEL 2 MENU INSTRUCTIONS
+DEVICES: The following information for the devices connected to every single loop can be
displayed: Address information, zone location texts, device models, analogue values, status of
devices (Enabled/Disabled).
