KK-641.002 Rev.No:1 01.08.12 ML-121X User Manual Page | 21
Manager in “Device Settings” section, can be silenced by pressing ‘Silence Alarm’ button.
+Automatic Reset Delay Configuration:
+Test Reset Delay:
-Test Reset Delay: 6-30 sec.: This indicates the
‘TEST’ duration, which is enabled from Access Level 2 Menu. After the selected value of time,
the output devices get back to its normal statuses without need of any further manipulation.
+Type A Dependency Reset Delay: In case of any fire
alarm from any device in defined zone, the panel goes into ‘PRE-ALARM’ mode. Sounders do
not ring; pre-alarm message is displayed on screen. In case of any other fire alarm from the
same zone within the adjusted time, the panel goes into ‘ALARM’ mode.
-Type A Reset Delay: 30-1800 sec.: In type A
dependency; in case of any fire alarm from the previously defined zone, countdown duration
starts. During this time, a second fire alarm is expected. If a second fire alarm is not received
from the same zone within the adjusted time (30-1800sec.), then the first alarm state is reset
and pre-alarm message on panel screen disappears.
+Type B Dependency Reset Delay: In case of any fire
alarm from any device in defined zone, the panel goes into ‘PRE-ALARM’ Mode. Sounders do
not ring; the pre-alarm message appears on screen. In case of any other fire alarm from any
zone (the same or different zone) within the adjusted time, the panel goes into ‘ALARM’ mode
and sounders ring.
-Type B Reset Delay: 30-1800 sec.: In type B
dependency; in case of any fire alarm from the previously defined zone, countdown duration
starts. During this time, a second fire alarm is expected. If a second fire alarm is not received
from the same or different zone within the adjusted time (30-1800sec.), then the first alarm
state is reset and pre-alarm message on panel screen disappears.
-Panel Time Settings: It is possible to set system time as year, month,
day, hour and minute. (The correct system time is vital in terms of proper registration of
events.)
+Panel Version Information: This feature is used to display the version
information of panel internal cards.
(xMCU, sLCU, xNCU, cPCU)
XMCU: 1.0.XX-0.0.0
SLCU: 1.0.XX-0.0.0
NCU: 1.0.XX-0.0.0
PCU: 1.0.XX-0.0.0
-Network Status: This feature is used to display other panel address
information in the network. (If there is a network)
+Event Logs: All events are saved to the memory of panel. It is possible to
display and print-out all events from due to the installation time of panel.
+View by Category: The event logs are displayed as being categorized
depending on the event types.
Fires: x
Evacuates: x
Faults: x
Pre-Alarms: x
-View by list: All events are sorted.
