11921 Slauson Ave. Santa Fe Springs, CA. 90670 (800) 227-4116 FAX (888) 771-7713

ELECTRICAL SCHEMATIC - JUMPER HARNESS ASSEMBLY

ORANGE

BLACK

WHITE

GREEN

RED

YELLOW

TERMINAL “F” LH STOP/TURN

TERMINAL “F” LH STOP TURN

TERMINAL “E” RH STOP/TURN

TERMINAL “D” STOP

TERMINAL “C” REVERSE

TERMINAL “B” TAIL

TERMINAL “A” GROUND

CONNECT TERMINALS TO

VEHICLE HARNESS

CONNECT TERMINALS TO

VEHICLE HARNESS

CONNECT MALE TERMINAL

TO COVER LIGHTS HARNESS

CONNECT MALE TERMINAL

TO COVER LIGHTS HARNESS

FOREIGN/DOMESTIC

FIG. 45-1

ISUZU

FIG. 45-2
