11921 Slauson Ave. Santa Fe Springs, CA. 90670 (800) 227-4116 FAX (888) 771-7713
46
ELECTRICAL SCHEMATIC - HOUSING COVER ASSEMBLY
(WITHOUT LIGHTS)
CONNECT TO
WIRING HARNESS
LICENSE PLATE
LIGHT
LH LICENSE PLATE
LIGHT
RH LICENSE PLATE
LIGHT
FIG. 46-1
SYSTEM DIAGRAMS - Continued
