11921 Slauson Ave. Santa Fe Springs, CA. 90670 (800) 227-4116 FAX (888) 771-7713
33
NOTE: This procedure only applies to platforms equipped with a fl ipover section.
The platform and fl ipover must be in the stowed position to accurately mea-
sure clearance between main housing and bottom of fl ipover. The platform
and fl ipover may be lowered below bed height in stowed position for better
access to measure clearance.
1. Gain access to main housing
and bottom of fl ipover section to
measure clearance (FIG. 33-1).
Refer to DMD Operation Manual
for instructions to lower platform
until arrow decals are aligned.
Ensure platform is kept folded
(stowed).
11/16” +/- 1/4”
PLATFORM & FLIPOVER
STOWED & LOWERED
FIG. 33-1
MEASURING CLEARANCE
FIG. 33-1A
2. Measure the clearance between main
housing and bottom of the fl ipover on
the RH side and LH side (FIG. 33-1A).
Clearance should be 11/16” +/- 1/4 on
both sides of the housing and fl ipover.
No adjustment is required with this
clearance. When clearance is incorrect,
on the LH and/or RD sides adjust the
clearance starting with with step 3.
MAIN
HOUSING
BOTTOM OF
FLIPOVER
ARROW
DECALS
MEASURE & ADJUST CLEARANCE FOR PLATFORM
WITH FLIPOVER
To Next Page
