11921 Slauson Ave. Santa Fe Springs, CA. 90670 (800) 227-4116 FAX (888) 771-7713
49
TABLE 49-1
DMD ELECTRICAL VALUES & TORQUE SPECIFICATIONS
SOLENOID SWITCH 12V 24V
Coil resistance: 5.4Ω @70ºF. ±15% 20.1Ω @70ºF. ±15%
Ampere: 2.2A 1.2A
Coil terminal torque: 10-15 lb-in max.
Contact terminal torque: 30-35 lb-in max.
LOWERING VALVE
Coil resistance: 6.6Ω @ 70ºF. ±15% 26.7Ω @ 70ºF. ±15%
Ampere: 1.8A 0.9A
Coil terminal torque: 15-45 lb-in max.
Valve cartridge torque: 25-30 lb-ft max.
Coil nut torque: 15-45 lb-in
FOLD/UNFOLD VALVE
Coil resistance: 8.0Ω @ 70ºF. ±15% 30Ω @ 70ºF. ±15%
Ampere: 1.5A 0.8A
Coil terminal torque: 3-4.5 lb-ft max.
Valve cartridge torque: 18.5-22 lb-ft max.
GROUND CABLE
Cap screw torque: 24 lb-ft max.
CYCLE COUNTER
Operation voltage 7V - 30V 7V - 30V
150 AMP CIRCUIT BREAKER
1/4”-20 nut torque: 50 lb-in max.
