Installation
Supplied Parts
Din Rear-Mount
Installation using the screw holes on both sides of the unit.
1. Screw holes on the side of the
unit.
2. Screws. Use either truss screws
(5x8mm) or flush surface screws
(4x8mm), depending on the shape of
the screw holes in the bracket.
3. Vehicle factory mounting bracket.
4. Dashboard or console.
5. Hook (remove this part)
Note: The mounting sleeve, outer
trim ring and the mounting strap
are not used for this method of
installation.
2 Keys
1 Hex Nut
2 Lock Washers
1 Sheet Metal Screw
1 Metal Support Strap
2 Flat Washers
1 Mounting Bolt
1 Faceplate Case (not
shown)
1 1/8” Stereo Cable
