MaxxMar MaxxLink - Advanced Wand Operations; Limit Setting Process; Setting Favourite Positions

5
Command Description Key Combination
Enter-Settings-Mode Put the motor into Settings Mode. (The motor will jog, and LED
will turn ON.)
Hold SET for 5 seconds
3
or
Hold HEAD for 3 seconds
3
Leave-Settings-
Mode
Return the motor to Normal Mode. (This will happen automati-
cally if no action is taken for 30 seconds. LED will turn OFF.)
Enter-Settings-Mode, then
Click SET
Adjust-Upper-Limit Start the process of setting the motor's upper rotational limit.
(See Limit Setting Process below)
Enter-Settings-Mode, then
Click UP
Adjust-Lower-Limit Start the process of setting the motor's lower rotational limit.
(See Limit Setting Process below)
Enter-Settings-Mode, then
Click DOWN
Save-Limit End the limit setting process, and save the limit at the current
position. (See Limit Setting Process below)
Adjust-Upper-Limit or
Adjust-Lower-Limit, then
Click SET
3
Reverse-Rotation Reverse the direction of rotation. i.e. switch up and down. Enter-Settings-Mode, then
Hold SET for 5 seconds
3
Set-Favourite-1 Set favourite position 1 at this position.
(See Setting Favourite Positions below)
Double-Click SET, then
Double-Click UP
3 4
Set-Favourite-2 Set favourite position 2 at this position.
(See Setting Favourite Positions below)
Double-Click SET, then
Double-Click DOWN3
4
3. Advanced Operations
Limit Setting Process
The motor’s upper and lower rotational limits are set individually. To set a limit:
1. Hold SET for 5 seconds (Enter-Settings-Mode).
2. Choose the limit to set. Click UP (Adjust-Upper-Limit) to adjust the upper limit, or Click DOWN (Adjust-Lower-
Limit) to adjust the lower limit.
3. Adjust the motor to the desired limit position using the UP and DOWN buttons.
4. Click SET to save the limit at this new position (Save-Limit). The motor will jog back-and-forth to conrm the that
the new limit has been saved.
Setting Favourite Positions
Once the upper and lower limits are set, the motor can store two favourite (intermediate) positions.
To set one of these positions:
1. Move to the position you want to store as a favourite position using UP and DOWN.
2. Use Set-Favourite-1 or Set-Favorite-2 to save. The motor will jog back-and-forth to conrm.
You can also clear a favourite position by setting it at the same place again. For example, to delete favourite position
1:
1. Move to that stored favourite position using GoTo-Favorite-1.
2. Call Set-Favourite-1 to delete. The motor will jog back-and-forth to conrm.
Note: you cannot set favourite positions until after the upper and lower limits are both set.
3- The motor will Jog back-and-forth after this command.
4- This entire key sequence must be completed within 10 seconds.
