9
9
10
33
17
ENG
Assembly – Multipress
Assembly Step 5:
Fix the loop on the end traction cable (47), which you already assembled in Step 1, using one of each of the following; hex-
agonal head screw M10x25 (33), two washers Ø10 (9) and a safety nut M10 (10) to the left and right-hand guide elements
on the dumbbell bar – see circled segment diagram.
