Maxxus Multipress 10.1 User Manual

35
59
42
39
33
30
19
32
16
18
51
37
ENG
Assembly Step 3
Now x the base frame (18) to the front mount of the sliding carriage (16). For this use two hexagonal head screws M8x20 (19), two
washers Ø8 (32) and a distance tube (30).
Assembly Step 4
Fix swivel bracket (35) using two hexagonal head screws M10x20 (39), two washers Ø10 (33) and distance tube (42) to the
mount on standpipe (51). To x swivel bracket (35) secure it with a safety split pin (59).
