Mayer MMDO9 - Door and Inner Glass Panel Removal

17
▲
Removing the doors
a. The oven door is fully open。
b. The latch hinges completely lifted。
c. Gently close the oven door until you hear
the sound of engagement, once they reach
a clamping position, with both hands holding
the door and continue to push, pull up at the
same time so that the hinge bolt removed
from the oven
d
.
e.
c.
.
C
▲
Remove the inner glass panel
b. Remove the inner glass .
A
B
a. Press and hold the two sides of the grid with
both hands to pull it out .
Pull out the grid
Right
Left
After cleaning, align the hinge with
the oven door. Latch and push
it
until it catches.
Take care to ensure
that the hinge and door are properly
aligned to avoid door damage.
If in doubt, contact the service centre -
information is listed on the back of
this user
manual.
With the oven door fully opened,
push the
latch down to it's initial
position to complete
the oven
door installation.
Locate the glass stopper and remove it.
Remove the
glass for cleaning.
To reinstall
the
inner glass, simply
gently place it back
onto the door and reinsert the
glass
stopper to secure the glass in place.
