Mayer TM 1010 - Starting the Machine for the First Time

20
1. Starting the machine for the first time
After reassembly the machine shall be checked as
per the following:
a)
Be sure not foreign materials, such as tools or
similar, are left on the turntable.
b)
Put main switch of the machine to OFF („Null”)
position before plug of the connection cable would
be connected to the socket.
c)
When the machine is connected, put the switch to
„1 ON” position.
d)
Put switch of turntable to „1 ON” position, while
switch of elevator and conveyor belt to right to
position „1”, as well as switch of drill to position „2”.
Press pushbutton „Start” on „Start-Stop” switch of
swinging cable and the turntable starts to rotate
counter clockwise.
If it would rotate clockwise then call for an
electrician to change phases at the connecting
cable.
Plates of the elevator shall be forwarded from
bottom towards top seeing from side of soil hopper.
Care shall be taken on the following:
With the potentiometer, “Soil” means:
• turn to the right
> larger amount of soil and more speed
• turn to the left
> smaller amount of soil and less speed
Warning!
• Switch position to right: elevator and conveyor
belt are moved in normal operational direction.
• Switch position to left: conveyor belt is moved in
normal operational direction while elevator is
moved in opposite direction.
Changeover switch „Drill” ("Bohrer"):
• switch position „2”: drill is rotated clockwise
> it excavates the soil.
• switch position „1”: drill is rotated counter-
clockwise > it compacts the soil.
(only possible with standard drill)
e)
In case of there were no problems found or unusual
noises heard during test operation, the machine
may be put into operation as it is described in
section „Operation”.
