Mayer TM 1010 - Technical Data

6
b) Working with automatic pot dispenser
When there is an automatic pot dispenser installed then feeding
by hand is not necessary and one person may be saved.
Further instructions are detailed in Operation instructions of pot
dispenser.
4. Technical data
Make:
Mayer
Machine type:
Potting machine
Series:
1010 frequency controlled
Length / width / height:
357 / 143 / 170 cm
Weight:
880 kg
Working height:
approx. 85 cm
Current consumption:
16 A
Control voltage:
24 V DC
Power connection:
400V/50Hz, 5-pole
Power input:
3,2 kW
Pot size:
T = 16: 5 to 22 cm diameter
T = 8: 15 to 30 cm diameter
(extra accessory)
for round and square pots
Capacity of soil hopper:
1,5 m³
4 m³ on request
Production speed:
800 - 4000 pots
Usable drill sizes:
2-13 cm
larger drill diameter on request
Workplace related emission value:
73dB (A)
