Testing Procedures
!
WARNING
To avoid risk of electrical shock, personal injury or death; disconnect power to oven before servicing, unless
testing requires it.
©2003 Maytag Appliances Company 16022506 11
Illustration Component Test Procedure Results
H1 Controlled Oven temperature
adjustment
Press BAKE pad.
Enter 550 on the digit-pad.
Immediately press and hold BAKE
pad for 3 seconds.
Oven can be adjusted from -35 to +35
degrees in 5-degree increments by
pressing AUTOSET pad. To avoid
over adjusting the oven, move
temperature 5 degrees each time.
Wait 4 seconds for the data entry timer
to expire to accept the change.
Temperature adjustment will be
retained even through a power failure.
While increasing or decreasing oven
temperature, this does not affect self-
cleaning temperature.
H1 Controlled Temperature display Press and hold Cancel and Bake
pads for 3 seconds.
This mode enables the user to indicate
°F or °C on the display.
H1 Controlled Clock Display Press and hold Cancel and Clock
pads for 3 seconds.
Allows clock to be toggled On or OFF.
H1 Controlled 24 Hour Clock Press and hold Cancel and Favorite
pads for 3 seconds.
Allows the time on the clock to be
toggled from 12 hour or 24 hour display.
H1 Controlled Factory Default Press and hold Cancel and Keep
Warm pads for 3 seconds.
Allows the clock to be reset to factory
settings.
H1 Controlled Twelve hour off Control will automatically cancel any
cooking operation and remove all
relay drives 12 hours after the last pad
touch.
See Sabbath mode to disable.
H1 Controlled Sabbath Mode Hold CLOCK pad for 3 seconds to
activate Sabbath mode.
Hold CLOCK pad for 3 seconds to
disable Sabbath mode.
“SAb” will be displayed and flash for
5 seconds.
Display will go back to time of day.
All pad inputs are disabled except for
CANCEL and CLOCK pads.
This mode disables the normal 12 hour
shutoff to allow operation of the bake
mode for a maximum of 72 hours.
H1 Controlled Child lock out Press and hold Cancel and Cook &
Hold pads for 3 seconds. “OFF” will
display where the temperature
normally appears. “LOCK” will display
flashing while door is locking.
To reactivate the control, press and
hold Cancel and Cook & Hold pads
for 3 seconds.
This is a safety feature that can be used
to prevent children from accidentally
programming the oven. It disables the
electronic oven control.
Child lockout features must be reset after
a power failure.
H1 Controlled Diagnostic Code
Display
See “Quick Test Mode”.
Cycle through the codes using the
number pads 1 through 5.
The last 5 diagnostic codes will be stored
in the non-volatile memory.
See “Description of Error Codes” for
explanation.
To Next Page
