Testing Procedures
!
WARNING
To avoid risk of electrical shock, personal injury or death; disconnect power to oven before servicing, unless
testing requires it.
22 16022506
©2003 Maytag Appliances Company
Test Mode
Follow procedure below to access the Test Mode.
1. Press SETUP pad.
2. Press DOWN ARROW pad three times until SERVICE is displayed.
3. Press SERVICE pad.
4. Press and hold BACK and ENTER pads for 5 seconds.
5. Press TEST pad.
NOTE: If the oven cavity temperature is greater then 400°F, the Test Mode cannot be activated or will abort the
mode if activated.
NOTE: Once the Test Mode is activated and a function is selected the control will activate the relay until the pad is
pressed again. Upon entering TEST Mode all relays are turned off except the DLB relays, which are turned
on. All relays are turned off when the TEST Mode is exited.
Pad Pressed Relay or Action Activated
Beep 1 Second Beep
Version Version of software
Last Fault Display last error code and oven configuration (single, double, convection, nonconvection)
DISP Test Display segments
UBAKE Upper Bake Element
UBROIL Upper Broil Element
UCONV Upper Convection Element
UCOOL Upper Cooling Fan
UCONV-H Upper High Speed Convection Fan
UCONV-L Upper Low Speed Convection Fan
UMDL Upper Motorized Door Lock
ULITE Upper Oven Light
LBAKE Lower Bake Element
LBROIL Lower Broil Element
LCONV Lower Convection Element
LCOOL Lower Cooling Fan
LCONV-H Lower High Speed Convection Fan
LCONV-L Lower Low Speed Convection Fan
LMDL Lower Motorized Door Lock
LLITE Lower Oven Light
