Testing Procedures
!
WARNING
To avoid risk of electrical shock, personal injury or death; disconnect power to oven before servicing, unless
testing requires it.
©2003 Maytag Appliances Company 16022506 23
Description of Error Codes
Error diagnostic codes can only be viewed by entering the Diagnostic Code Display Mode.
Each error code is four digits long and is created based on the following table.
Digit Description
1
st
Primary System: 1 – Local to the control circuit board
3 – Sensor or meat probe
4 – Control input
9 – Door lock
2
nd
Measurable: d – Diagnostic failure: measurable parameter
c – Control related error, replace control
3
rd
Primary failure mechanism
4
th
Oven Cavity: 1 – Upper oven (or single cavity oven)
2 – Lower oven
c – Control specific
Diagnostic Code Checking
Code Description When Checked Detection
1c1c Shorted key Always 1 minute
1c2c Keyboard tail disconnected Always 1 minute
1c31 Cancel key circuit problem Always 20 sec
1c32 Cancel key circuit problem Always 20 sec
1c4c Power micro communication failure Always 20 sec
1c6c EEPROM error When accessing EEPROM 3 tries
1c7c Control not calibrated Always 3 tries
1c81 Cook profile corrupted in EEPROM Cook or clean programmed 3 tries
1c82 Cook profile corrupted in EEPROM Cook or clean programmed 3 tries
1d11
Runaway temperature (650°F), door unlocked
Latch unlocked 1 minute
1d12
Runaway temperature (650°F), door unlocked
Latch unlocked 1 minute
1d21
Runaway temperature (950°F), door locked
Latch locked 1 minute
1d22
Runaway temperature (950°F), door locked
Latch locked 1 minute
3d11 Temperature sensor failure (open) Cook or Clean active 20 sec
3d12 Temperature sensor failure (open) Cook or Clean active 20 sec
3d21 Temperature sensor failure (short) Cook or Clean active 20 sec
3d22 Temperature sensor failure (short) Cook or Clean active 20 sec
3d41 Meat probe shorted Probe cook programmed 20 sec
3d51 Meat probe not calibrated Always 3 sec
4d11 Door switch position failure Clean or Keyboard Lockout active 1 minute
4d12 Door switch position failure Clean or Keyboard Lockout active 1 minute
4d21 No Reverse Airflow Fan rotation (no/low RPM) Cook or Clean programmed 1 minute
4d22 No Reverse Airflow Fan rotation (no/low RPM) Cook or Clean programmed 1 minute
4d31 Reverse Airflow Fan state error
(on when supposed to be off)
When supposed to be off 1 minute
4d32 Reverse Airflow Fan state error
(on when supposed to be off)
When supposed to be off 1 minute
4d41 High Reverse Airflow Fan rotation, high RPM Cook or Clean programmed 1 minute
4d42 High Reverse Airflow Fan rotation, high RPM Cook or Clean programmed 1 minute
4d51 Door switch circuit failure Convect, Clean, or Keyboard Lockout
programmed
1 minute
4d52 Door switch circuit failure Convect, Clean, or Keyboard Lockout
programmed
1 minute
9d11
Latch will not lock
6
Latch should be locked See note 6
9d12
Latch will not lock
6
Latch should be locked See note 6
9d21
Latch will not unlock
6
Latch should be unlocked See note 6
9d22
Latch will not unlock
6
Latch should be unlocked See note 6
9d31
Latch both locked and unlocked
6
Latch should be locked or when lock attempted See note 6
9d32
Latch both locked and unlocked
6
Latch should be locked or when lock attempted See note 6
