Testing Procedures

WARNING

To avoid risk of electrical shock, personal injury or death; disconnect power to oven before servicing, unless

testing requires it.

14 16022506

Amana Matrix

Control Panel Assembly

Continuity is indicated as follows:

1000 – 6600 Ω for Cancel pad

1000 – 15000 Ω for All other pads

Pad

Lower Cancel

Lower Broil

Lower Bake

Delay

Clock

Favorite

Lower Clean

Upper Clean

Upper Cancel

Convect

Lower Light

Upper Keep Warm

Upper Light

Autoset

Lower Keep Warm

Convect Roast

Upper Bake

Timer 2

Cook & Hold

Upper Broil

Timer 1

Trace

4 & 15

5 & 14

6 & 14

7 & 14

8 & 15

4 & 14

5 & 6

6 & 7

7 & 8

8 & 14

1 & 2

4 & 17

4 & 5

6 & 17

6 & 16

8 & 16

5 & 15

4 & 16

11 & 12

5 & 17

15 & 17

5 & 16

7 & 17

7 & 15

6 & 15

14 & 17

15 & 16

16 & 17

7 & 16

14 & 15

8 & 17

Measurement

Continuity

Jenn-Air Matrix
