-9-
GAS CONVERSION
To access the regulator from front of range, remove the
storage drawer or warming drawer.
To remove storage drawer: Pull out to the first stop
position. Lift up front of drawer and pull to the second
position, grasp sides and lift up and out to remove drawer.
To replace: Fit the drawer rollers onto the rails. Lift up
drawer front and gently push in to first stop position. Lift
up and continue to slide drawer to the closed position.
TO REMOVE WARMING DRAWER:
1. Empty drawer and pull out to its full open position.
2. Locate the black triangle levers on each side of the
drawer.
LEVER
3. Press the lever DOWN on the RIGHT side and lift the
lever UP on the LEFT side at the same time. Then pull
drawer out another inch.
4. Carefully pull the drawer all the way out holding on to
the sides, not the drawer front.
TO REPLACE WARMING DRAWER:
a. Pull the bearing glides to the front of the chassis glide.
(See picture below).
BEARING GLIDE
b. Align the glide on each side of the drawer with the glide
slots on the range. (See picture below).
c. Push the drawer into the range until levers “click”
(approximately 2²). Pull the drawer open again to seat
bearing glides into position. If you do not hear the
levers “click” or the bearing glides do not feel seated
removethedrawer and repeat stepsathrough c.This
will minimize possible damage to the bearing glides.
