16 Maytag Co. 112204-6
6. Using slip-joint pliers, tighten the coupling with an
additional two-thirds turn.
NOTE: Do not overtighten. Damage to coupling can result.
7. Install filter or strainer to the water supply line.
8. Connect the new flexible supply line/coupling with
washers to the 3/4” 11.5 NH hose adapter.
• Screw coupling on by hand until seated on the hose
adapter.
• Using slip-joint pliers, tighten the coupling with an
additional two-thirds turn.
NOTE: Do not overtighten. Damage to coupling can result.
9. Connect the other end of the new flexible supply line/
coupling with new washers to the water supply valve.
• Screw coupling on by hand until seated on the supply
valve.
• Using slip-joint pliers, tighten the coupling with an
additional two-thirds turn.
NOTE: Do not overtighten. Damage to coupling can result.
10. Turn water supply to dryer on.
11. Check for leaks.
• Check for leaks at the flexible supply line/coupling, the
3/4”-11.5 NH hose adapter (both ends).
12. Reinstall the rear panel.
13. Reconnect the power.
NOTE: Do not overtighten. Damage to coupling can result.
Preparation for Operation / Start-Up _
The following items should be checked before attempting
to operate the dryer:
• Read all “WARNING” and “DIRECTION” labels attached
to the dryer.
• Check incoming supply voltage to ensure that it is the
same as indicated on the data label.
• Ensure that all gas shutoff valves are in the open
position.
• Ensure all back panels (guards) and electric box covers
are in place.
• Ensure the service doors are closed and securely in
place.
• Ensure the lint door/drawer is securely in place.
• Rotate the tumbler (drum) by hand to ensure it moves
freely.
• Check bolts, nuts, screws, terminals, and fittings for
tightness and security.
• Check that the vent is connected to the dryer and is
exhausted to the outdoors.
Preoperational Test ___________________
All dryers are thoroughly tested and inspected before leaving
the factory. However, a preoperational test should be
performed before the dryer is publicly used. It is possible
that adjustments have changed in transit or due to marginal
location (installation) conditions.
Turn on electric power to the dryer.
Refer to the operating instructions below for starting your
dryer.
Open all shutoff valves.
When a gas dryer is first started (during initial start-up), it
has a tendency not to ignite on the first ignition attempt. This
is because the gas supply piping is filled with air, so it may
take a few minutes for the air to be purged from the lines.
NOTE: During the purging period, check to ensure that all
gas shutoff valves are open.
Tumbler Coating
The tumbler is treated with an oil coating. To remove this
coating, dampen a good amount of old garments or cloth
material with a solution of water and nonflammable mild
detergent and tumble them in the tumbler without heat to
remove this coating.
Microprocessor Programs/Selections
Each microprocessor controller (computer) has been
preprogrammed by the factory with the most commonly used
parameter (program) selections. If computer program
changes are required, refer to the computer programming
manual, which was shipped with the dryer.
Operating Instructions _______________
IMPORTANT: For more detailed information regarding the
microprocessor controller (computer), refer to the
microprocessor user’s manual included with the dryer.
Coin Models
Microprocessor Controller (Computer)
When the microprocessor controller (computer) is in the
ready state, the L.C.D. screen will display “Ready, Insert
$XX.XX (amount) to Start”.
Insert coin(s). Once the correct “Amount to Start” has been
inserted, the L.C.D. will display “Select Temperature”.
Select temperature by pressing “Heavy Duty,” “Normal,” or
“Delicate.” The cycle will start and the L.C.D. will display the
Dry Cycle selected and the remaining time.
The dryer will continue through the drying cycle, until the
vended time has expired.
NOTE: To stop the dryer, open main door. Continuation of
the cycle will resume only after the door has been closed
and any one of the 3 temperature selections is pressed.
