Maytag MDG35 - MDG35 Specifications

112204-6 Maytag Co. 5
MAXIMUM CAPACITY (DRY WEIGHT) 35 lb
15.88 kg
TUMBLER DIAMETER 30”
76.20 cm
TUMBLER DEPTH 30”
76.20 cm
TUMBLER VOLUME 12.27 cu ft
347.44 L
TUMBLER / DRIVE MOTOR 1/4 hp
0.19 kW
BLOWER / FAN MOTOR 1/2 hp
0.37 kW
DOOR OPENING (DIAMETER) 19-3/8”
49.21 cm
DOOR SILL HEIGHT 37”
93.98 cm
WATER CONNECTION 3/4”-11.5 NH
DRYERS PER 20’ / 40’ CONTAINER 14 / 28
DRYERS PER 53’ TRUCK 36
VOLTAGE AVAILABLE 120 1ø 2w 60 Hz
APPROXIMATE NET WEIGHT 462 lb
209.6 kg
APPROXIMATE SHIPPING WEIGHT 492 lb
223.2 kg
AIRFLOW 319 cfm
9.03 cmm
HEAT INPUT 64,000 Btu/hr
16,128 kcal/hr
EXHAUST CONNECTION (DIAMETER) 6”
15.24 cm
INLET PIPE CONNECTION 1/2” M.N.P.T.
MDG35 Specifications _____________________________________________________________
GAS
Shaded areas are stated in metric equivalents 6/17/13
NOTE: The manufacturer reserves the right to make changes in specifications at any time without notice or obligation.
