Maytag MDG35 - Table of Contents

4 Maytag Co. 112204-6
Important Information ________________
IMPORTANT: A means of restraint must be used to avoid
straining of the gas supply when the dryer is moved.
An external means of power removal (disconnect device)
must be provided by the installer.
List of Acronyms _____________________
HVAC Heating, Ventilating, and Air-Conditioning
in wc Inches of Water Column
L.C.D. Liquid Crystal Display
L.P. Liquid Propane
UL Underwriters Laboratory
“Caution: Label all wires prior to
disconnection when servicing controls.
Wiring errors can cause improper
operation.”
«Attention: Au moment de l’entretien des
commandes, étiquetez tous les fils avant
de les débrancher. Des erreurs de
câblage peuvent entraîner un
fonctionnement inadéquat et dangereux.»
WARNING
The dryer must never be operated with
any of the back guards or service panels
removed. Personal injury or fire could
result.
The wiring diagram for the dryer is located
behind the front control panel on the right
side.
Table of Contents ______________
MDG35 Specifications ............................................. 5
MDG52 Specifications ............................................. 6
MDG78 Specifications ............................................. 7
Installation Procedures........................................... 8
Location Requirements .......................................... 8
Dryer Enclosure Requirements .............................. 9
Fresh Air Supply Requirements.............................. 9
Exhaust Requirements........................................... 9
Electrical Information............................................. 11
Gas Information.....................................................12
Water Information (PN Models Only).....................15
Preparation for Operation / Start-Up ......................16
Preoperational Test ...............................................16
Operating Instructions ...........................................16
Shutdown Instructions ...........................................17
Service / Parts Information ...................................17
Service ..................................................................17
Parts .....................................................................17
Routine Maintenance.............................................17
Cleaning ................................................................17
Data Label Information..........................................18
