Maytag MDG35 - MDG78 Specifications

112204-6 Maytag Co. 7
MAXIMUM CAPACITY (DRY WEIGHT) 75 lb
34.02 kg
TUMBLER DIAMETER 37”
93.98 cm
TUMBLER DEPTH 35-1/2”
90.17 cm
TUMBLER VOLUME 22.09 cu ft
625.52 L
TUMBLER MOTOR 3/4 hp
0.56 kW
BLOWER / FAN MOTOR 1/2 hp
0.37 kW
DOOR OPENING (DIAMETER) 27-3/8”
69.53 cm
DOOR SILL HEIGHT 27-5/16”
69.37 cm
WATER CONNECTION 3/4”-11.5 NH
DRYERS PER 20’ / 40’ CONTAINER 9 / 20
DRYERS PER 48’ / 53’ TRUCK 25 / 27
VOLTAGE AVAILABLE 120 1ø 2w 60 Hz
APPROXIMATE NET WEIGHT 745 lb
337.93 kg
APPROXIMATE SHIPPING WEIGHT 775 lb
351.53 kg
AIRFLOW 600 cfm
17.00 cmm
HEAT INPUT 130,000 Btu/hr
32,760 kcal/hr
EXHAUST CONNECTION (DIAMETER) 8”
20.32 cm
INLET PIPE CONNECTION 1/2” M.N.P.T.
MDG78 Specifications _____________________________________________________________
Shaded areas are stated in metric equivalents 10/3/13
NOTE: The manufacturer reserves the right to make changes in specifications at any time without notice or obligation.
GAS
