28
MFS80 MFS100 MFS125
Washing Functions
Washing 38 RPM 38 RPM 38 RPM
High Extracting 830 RPM 830 RPM 830 RPM
G-Factor Max. 350 Max. 350 Max. 350
Water Connection
Water Inlet Connection BSP 1"
Water Pressure Range 14.5–116 PSI/0.1–0.8 MPa/1–8 bar
Recommended Water Pressure 43–73 PSI/0.3–0.5 MPa/3–5 bar
Maximum Water Temperature 194°F/90°C
Drain Connection
Drain Valve Diameter 2 x 3"/76 mm
Flow Rate 80 gal/300 dm² min.
Steam Connection
Steam Connection G 3/4"
Steam Pressure 44–116 PSI/0.3–0.8 MPa/3–8 bar
Press Air Connection**
Connection G 1/4"
Pressure 43–73 PSI/0.3–0.5 MPa/3–5 bar
Dispensing
Powder Dispenser 5
Liquid Soap Supply 8
Hydraulic Provision 6
Consumption (1) Light soiled 140°F/60°C wash
Without Electric Heating 1.1 kWh 1.7 kWh 2.1 kWh
With Electric Heating 5.3 kWh 8 kWh 12 kWh
Steam 0.101 lbs.s
-1
/ 0.123 lbs.s
-1
/ 0.168 lbs.s
-1
/
0.046 kg.s
-1
0.055 kg.s
-1
0.076 kg.s
-1
Working Conditions
Ambient Temperature 41°F (+5°C) to 95°F (+35°C)
Relative Humidity 30% to 90% without condensation
Height Above Sea Level up to 3280 ft/1000 m
Storage Temperature 34°F (1°C) to 131°F (+55°C)
Anchoring
Max. Static Load on Floor 14416 N 18162 N 19574 N
Max. Dynamic Load on Floor 12709 ± 2747 N 16083 ± 2943 N 17064 ± 3139 N
Frequency of Dynamic Load 14 Hz 14 Hz 14Hz
Noise
Equivalent Noise Level LAEQ (dB[A]) 80.8 dB(A) 77 dB(A) 77 dB(A)
** Valid for washers which have water valves with
air-operated control.
(1) Depends on cold and hot water supply temperature and
wash program setup.
Technical Specications Cont. (Models MFS80, MFS100, and MFS125)
