Technical Specications (Models MFS180, MFS230, and MFS275)
* Maximum dimensions, including protruding parts
–6% to +10% of the voltage supply +1 Hz
MFS180 MFS230 MFS275
Washer Dimensions*
Width 60.23" (1530 mm) 70.86" (1800 mm) 73.03" (1855 mm)
Depth 70.86" (1800 mm) 79.13" (2010 mm) 79.72" (2025 mm)
Height 78.73" (2000 mm) 76.77" (1950 mm) 81.88" (2080 mm)
Packing Dimensions
Width 66.53" (1690 mm) 73.42" (1865 mm) 78.73" (2000 mm)
Depth 76.77" (1950 mm) 83.66" (2125 mm) 85.43" (2170 mm)
Height 86.61" (2200 mm) 92.33" (2345 mm) 92.12" (2340 mm)
Transportation Volume 256 ft
3
(7.25 m
3
) 328 ft
3
(9.29 m
3
) 359 ft
3
(10.16 m
3
)
Inner Drum Dimensions
Diameter 43.70" (1110 mm) 47.24" (1200 mm) 39.48" (1300 mm)
Depth 33.00" (838 mm) 33.85" (860 mm) 34.25" (870 mm)
Drum Volume 213 gal. (807 dm
3
) 265 gal. (1003 dm
3
) 312 gal. (1180 dm
3
)
Door Opening 20.86" (530 mm) 20.86" (530 mm) 20.86" (530 mm)
Weight
Net 5820 lb (2640 kg) 7055 lb (3200 kg) 7232 lb (3280 kg)
Gross 6239 lb (2830 kg) 7496 lb (3400 kg) 7695 lb (3490 kg)
Electrical Requirements
3x208–240V 50/60 Hz
3x380–415V 50/60 Hz
Power Supply – Deviations
Input of Washer
Electric Heating 67.5 kW 75 kW – –
Steam or Without Heating 11.25 kW 15.25 kW 18.75 kW
Nominal Motor Output 11 kW 15 kW 18.5 kW
Residual Current Device (RCD) 100 mA, Class B
Supply Protecion Device Use “slow” type protection devices (circuit breakers: Curve D)
Steam or Without Electric Heating
3 x 208–240V 50/60 Hz 63A 75A 100A
3 x 380–480V 50/60 Hz 32A 50A 63A
Electric Heating 67.5 kW (3 x 208–240V) 250A – –
Electric Heating 67.5 kW (380–480V) 125A – –
